SPECIFICHE TECNICHE WEIGHT 24,5 kg per unit FINISHES Black Gloss / White Gloss / Walnut DIMENSION (H X W X D) 1025 x 175 x 344 mm with terminal* DIMENSION (H X W X D) 1072 x 272 x 344 mm with terminal with plinth* DESIGN Three-way bass reflex FREQUENCY RANGE 38 Hz – 50 kHz (-6 dB) TYPICAL IN-ROOM BASS RESPONSE 29 Hz (-6 dB) FREQUENCY RESPONSE 52 Hz – 28 kHz (±3 dB) CROSSOVER FREQUENCIES 400 Hz, 2.7 kHz HARMONIC DISTORTION (90 dB, 1m) <1% 75 Hz and above; <0.5% 110 Hz – 20 kHz SENSITIVITY 87 dB MAXIMUM OUTPUT 110 dB AMPLIFIER REQUIREMENTS 15 – 200W NOMINAL IMPEDANCE 4 Ω (min. 3.2 Ω) DRIVE UNITS Uni-Q Driver Array: HF: 25 mm vented aluminium dome with MAT, MF: 125 mm aluminium cone BASS DRIVER LF: 2 x 130 mm hybrid aluminium cone
