SPECIFICHE TECNICHE MODEL: REFERENCE 8b CABINET FINISH: Deep Piano Black WEIGHT: 34 Kg DIMENSION (H X W X D): 398 x 365 x 429 mm (15.7 x 14.4 x 16.8 in) DESIGN: Force cancelled closed box INPUTS: RCA phono sockets, Analog XLR socket, Speaker level inputS FREQUENCY RANGE: Free Field: 18 Hz (-6 dB) FREQUENCY RESPONSE: 24 Hz at 90 dB output in free-space mode (±3 dB) NET INTERNAL VOLUME: 23 L MAXIMUM PUTPUT: 110 dB (peak sound pressure level at 1 m 50 Hz) AMPLIFIER TYPE: 2 x 500 W Class D with switched mode power supply and DSP based control section DRIVE UNITS: LF 2 x 225 mm (9 in) POWER REQUIREMENTS: 100V – 120V / 220V – 240V ~50/60Hz POWER CONSUPTION: 1000 W LINK OUT: RCA phono socket VARIABLE LOW PASS FILTER: Variable frequency: 40Hz to 160Hz Variable slope: 12dB/oct, 18dB/oct, 24dB/oct LFE mode: 350Hz, 18dB/oct
